Standard Fittings
1. Rating and diagram plate.
2. Earthing terminals - 2 Nos.
3. Lifting lugs.
4. Oil level indicator (Plain)
5. Drain-cum bottom filter valve with plug.
6. Oil filling hole with plug on conservator.
7. Oil conservator with drain plug.
8. Air release plug.
9. Silicagel air breather.
10. Bi-directional flat rollers.
11. HV terminals-outdoor bushings.
12. LV terminals-outdoor bushings.
13. Radiators.
14. Filter valve with plug.
15. Thermometer pocket.
16. Oil temperature indicator.
17. Externally operated off circuit tap
changing switch.
18. Explosion vent.
19. Sampling value (for 2000 KVA & above
transformers only)








Accessories on Request
1. LV and HV cable boxes
2. Winding temperature indicator (WTI).
3. Buchholz relay
4. Magnetic oil level gauge
5. Marshalling box
6. Disconnecting chamber
7. Oil temperature indicator with electrical
contacts (OTI)
8. Pressure relief valve
